Gearbox structure of a beach cycle includes a gearbox which may transmit a power of an engine to a power shaft and a propeller shaft. A clutch mounted between the change gears of the gearbox can be shifted by a gear shift device into a neutral position, a reverse gear position and a forward gear position.
The gear shift device includes a gear lever which rotates a sector shaped gear which rotates a gear shift cam shaft which is formed with a slot for driving a gear shift drive fork which shifts the clutch to the neutral position, the reverse gear position, and the forward gear position. The gearbox is further provided with a force increase gear, and the propeller shaft is additionally provided with a drive gear which meshes with a helical gear of a distance calculator which has a connecting line externally connected to an odometer.
A conventional beach cycle in accordance with the prior art uses a CVT gear shift to transmit the power of the engine into the gearbox. The conventional beach cycle usually includes a forward gear only, without a force increase gear, so that when the beach cycle is trapped in a muddy situation, it cannot move forward easily. In addition, the distance calculator used for the odometer is mounted outside of the gearbox of the conventional beach cycle, so that the distance calculator is easily worn out.
The primary objective of the present invention is to provide a gearbox structure of a beach cycle, wherein the gearbox is further provided with a force increase gear, and the propeller shaft is additionally provided with a drive gear which meshes with a helical gear of a distance calculator which has a connecting line externally connected to an odometer.
In accordance with the present invention, there is provided a gearbox structure of a beach cycle comprising:
Gearbox for transmitting a power of an engine through a CVT gear shift to a power shaft which is fitted with a propeller shaft, the power shaft and the propeller shaft directly meshing with each other through a reduction gear and change gears mounted on a gear shift shaft, and through steering gears mounted on a steering shaft, the change gears including a backward used change gear, and a forward used change gear, the propeller shaft provided with a forward used drive gear meshing with the forward used change gear.
The gear shift shaft having an outer periphery formed with outer splines, a first clutch slidably mounted on the outer splines of the gear shift shaft, the first clutch formed with locking blocks engaged with locking blocks formed on the change gears, so that the first clutch can be shifted by a gear shift device into a neutral position, a reverse gear position and a forward gear position, the gear shift device including a gear lever which rotates a sector-shaped gear which meshes and rotates a gear shift cam shaft which is formed with a first slot having a track variation for driving a first gear shift drive fork which drives and shifts the first clutch to the neutral position.
The reverse gear position, and the forward gear position, the gearbox provided with a positioning spring, and a positioning ball, the gear shift cam shaft formed with positioning recesses each mating with a respective gear position and each co-operating with the positioning spring, and the positioning ball, so that the gear shift cam shaft can be rotated to a correct gear position;
In addition, the propeller shaft in the gearbox is additionally provided with a drive gear which meshes with the helical gear of a distance calculator, and the connecting line of the distance calculator is externally connected to an odometer (not shown). In such a manner, the distance calculator is mounted in the gearbox. How To Learn French Videos Reva tory burch employ pertaining to distinct climate circumstances Choosing Your Beach Bridesmaid Dresses Travel Clubs - Can They Save You Money On Your Following Getaway? Who needs medication to stop alcoholism when a trip to Vermont could work instantaneously? India Tours Choose Your Destination Of Interest Reva tory burch apply intended for distinct climate ailments Have A Merry Christmas With A Furry Buddy! Celebrity Engagement Ring Trends Holiday In Goa And Registration At Hotel Chains The Top Five London Accident Blackspots Gianni Truvianni's "South Africa 2010", The Netherlands Solid In 2-1 Win Over Slovakia Discounted tory burch shoes apply regarding several climate ailments
